Chiller section
In this page you find the available Chillers . Contact us for more information. you can download the full description .
Azane Nh3 chillers aircooled by Star refrigeration
Available: 3 Off
Print description
AZANEchillers 2014
Azane Chillers manufacturer plant information
AZANEchillers 2014
very nice maintened Azane chiller constructed By star refrigeration. very stable and Industrial .
Duty :
275kW at =1/-5 ºC .
NH3/ glycol.
year of build: :2014
At this moment the chillers are set-up for different temperature ranges -they can be set-up for the same temperature range . Check the plant information
2 very nice maintained PAC163 packs based on the Sabroe Sab 163 R – these are compressors , which regulate the capacity by drive speed. Therefore no internal loses by the slide valve.
These unit are from 2007. NH3 design.
Installed E-motor power : 160 kW designed for VSD – variabel drive speed.
Low nh3 CHARGE 175 kg.
Controlled by converter and Unisab II.
dimensions: 5800 x 2660 x 2850 mm
weight: 8800 kg
Sabroe chill PAC based on SMC106E 2007
Available: 1 Off
Print description
Sabroe Chill PAC based on SMC 106E 2007
very nice maintained Chill Pac. The compressor is a SMC106E . a unisab Pro II is the controller.
The unit is from 2007. NH3 design.
Installed E-motor power : 132 kW.
Low nh3 CHARGE 27 kg.
Controlled Unisab II.
dimensions: 3200 x 1000 x 2000 mm
weight: 4.045 kg
Complete Sabroe Chiller in 45 Ft based on 2 Chill pac SMC112E. 2008
Available: 2 Off
Print description
45 Ft Container chiller based on 2 Chill pac SMC112E.
Complete chiller in 45 Ft container . Constructed in 2008 by Sabroe.
In the 45 ft container are 2 Chill pac SMC112E build in . Each compressor is driven by 315 kW E-motor and controlled by Unisab 3. The containers are constructed in 2008.
The are 2 containers available.
refrigerant NH3.
All documentation is available .
Down load : the description to get a impression
unused CMO24 compresser unit with chiller parts chiller Sabroe PAC 151 Duo pack
Available: 1 Off
Print description
unused SabroeCMO24 with unused chiller parts 2015
This project was in installation proces, however due change of plans canceled- the installation was never filled with NH3.
Available is :
- unused CMO 24 compressor Nh3 – E-motor 30 kW – unisab III controller
- thermowave heatexchanger
- Q-plate evaporator
- liquid vessel
- liquid separator
- oil recovery system
Sabroe PAC 151 Duo pack
Available: 1 Off
Print description
Sabroe PAC 151 duo pack NH3/ glycol chiller 2008
Duty :
674kW at – 9,5/ +32 ºC .
NH3/ glycol.
year of build: :2008
The chiller is based on 2 Sabreo 151 units . 1 VSD driven.
Both compressor units are controlled by it’s own Unisab Pro II.
The glycol unit is suited with a Alfa laval heat exchanger and executed in Pharmaceutical Grade. The control System is Siemens.
Heavy duty glycol chiller based on an Howden WRV model compressor
Available: 2 Off
Print description
Star/Howden glycol chiller WRV204/145.50 NH3 2014
Duty :
480 kW at -15/- 20 ºC glycol side or 300 kW at -25/-30ºC
The glycol Chiller is based on the Howden MK6/WRV204/145.50 compressor. The installed Vi= 5.0- The compressor is suited with a electronic part load indication, which indicate the position of the slide valve in 4-20 mA to the Central control unit. The installed E-motor is 220 kW and special designed for VSD drive. The Chiller operates in 1500-3600 RPM.
The glycol unit is suited with a Alfa laval heat exchanger and executed in Pharmaceutical Grade. The control System is Siemens.
The unit is build in 2014 by the Well known Star Refrigeration, which have a long history with Howden compressors. At this moment there are 2 complete Chillers available.
The Running hours are approx. 12000 hours
Dimensions:
6010 X 1450 x 2880 mm
Weight : 11225 kg
Complete low temperature Glycol Chilling System – 45°C 2019 Based on 1 Grasso RC7212E on VSD. 2000
available : 1 off
Print description
Complete Glycol Chilling systeem low temperature - 45 degrees C of 2000
Well maintained Glycol low temperature plant -45 Degrees C. 109 KW . Installed E-motor is 75 kW
Based on the Grasso RC7212E compressor.
The unit a complete with frequency converter , controle system and Baltimore condensor .
Dimensions: 5000 x 2600 x 3000 mm
Weight: 6000 kg
Complete Glycol Chilling System 2019 Based on 3 Trane RTAC450
available : 1 off
Print description
Complete Glycol Chilling systeem ) production hours 2019
Glycol plant available brand new -not 1 production hour :
- 3 trane Syntesis RTAC450 ( 815 kW at glycol -2/-8º C)
- cold side buffertank 5000 ltr
- hot side buffertank 3000 Ltr
- 4 pc VSD chiller circulation pumps
- 4 pc VSD cooler circulation pumps
- 2 pc Circulation pumps for defrosting
- 2 pc pumps for heat recovery
- 28 pc Lu-VE CS80W 3712 N6
- 4 pc Lu-VE CD 63H Dual Dish coolers
- Chiller control panel
ºThe complete plant has only commission hours. The plant war prepared for a new owner for long term rent. The effect of covid19 has other plants. 3 Brand new Chillers Trane Syntesis RTAC450 , 28 LU-VE
3 Pc Trane SYNTESIS RTAC450
Capacity: 815 kw Glycol entry -2ºC/ Glycol out -8ºC
Refrigerant : 143A
circuits : 4
compressors: 4
Operation: compressor and fans VSD controlled
Dimensions of one chiller:
13510 X 2200 x 2526 mm
Weight : 10170 kg
2 pc Trane RTHC 01EKL2595 Chillers
available : 2 off
Print description
Trane RTHC glycol chillers 2001
Two pc RTHC glycol chillers of 2001.|
Refrigerant R134A
compressor block type : CHHC1D1FOHO
nice pricing
Very Nice Trane CGAM070 – year of construction 2016.
Capacity : 186 kW
Refrigerant: R410A
Number of Compressors: 4
Number of Circuits: 2
The chiller was used in Climate control system. Very nice maintained ( service contract)
Dimensions:
4018 X 2245 x 2155 mm
Weight : 2670 kg
Brand new Carrier AQUA Force 30XW-V1280A009-VAR18 with transport damage 2019
Available : 1 off
Print description
New Carrier Aqua Force 30XW-V1280A009-VAR18 2019
The Carrier Aqua Force 30XW-V1280A009 Var18 is suited with the latest models thunderbolt compressor – VSD driven
refrigerant :R143a
Volume :240 kg
Capacity indications:
Condition by heating full load:
1428 kW COP 4,61 (evaporator entry/ exit water temperature 10ºC/ 7°C- condenser entry / exit water temperature 40ºC/45ºC, fouling factor evaporator/condenser 0M2K/W.
Condition by cooling full load:
1305 kW COP 5,50 (evaporator entry/ exit water temperature 12ºC/ 7°C- condenser entry / exit water temperature 30ºC/35ºC, fouling factor evaporator/condenser 0M2K/W.
The damage is basic on the enclosure and one junction box of one of the compressor – The VSD drives are in tact . Some Small external line neer to be replaced- no damage to the heat exchanges nor compressor blocks.
Belt qty: 1
Belt width: 5800 mm
14 levels/ 22 shelfs
Belt length: mm
Product Gap: 435 mm
Dimensions:
4730 X 1255 x 1997 mm
Weight : 7398 kg ( in operation)
Small industrial glycol cooling 8 kW 2018
Avialable: 1 off
print description
Industrial glycol cooling 8 KW 2018
Small industrial glycol Chiller complet stainless steel enclosure- DX system 8 kW Based on the refrgerant R507- The compressor is a hermetic scroll compressro of Copeland- aircooled condensor – liquid evaporator, 50 ltr buffertank -recycle water/ glycol pump .
refrigerant filling :2,2 kg
Cooling capacity : 8 kW
Cooling medium: Water/ Propylene glycol ( 65%/35%)
Temperature Setting : -8ºC/ -2ºC
Water in : -4ºC
Water out : -8ºC
Flow : 1,9 m3/hr
Connections: 2 x G1 Female
Buffertank : 50 Ltr
Design Ambient temperature range: +30ºC
Ambient temperature range: -15ºC/+40ºC
Power supply : 460V -3ph
Control power: 24 VDC
Installed power: 5,5 kW
Power consumption nominal : 4,5 kW
Dimensions:
1390 X 1170 x 1000 mm
Weight :
empty: 330 kg
In operation: 385 kg
Trane spare overhauled block CHHC1B2F0L0-SNUA5GS5471 2010
Avialable: 1 off
Print description
Trane Spare overhauled compressor block CHHC1B2F0L0-SNUA5GS5471 2010
Overhaul Trane compressor model CHHC1B2F0L0-SNUA5GS5471 this compressor is overhauled in 2016. Was spare compressor for the owner of the chiller.
